feign核心组件#

Encoder和Decoder：编解码组件。SpringEncoder和ResponseEntityDecoder
Contract：解析spring mvc相关组件。SpringMvcContract
Feign.Builder：FeignClient的一个实例构造器，builder模式
FeignClient：LoadBalancerFeignClient ，底层整合ribbon

feign的使用和自定义配置

@FeignClient(name = “ServiceA”, configuration = MyConfiguration.class)
public interface ServiceAClient {

}

public class MyConfiguration {
@Bean
public RequestInterceptor requestInterceptor() {
return new MyRequestInterceptor();
}

}

java

feign的入口#

@EnableFeignClients，使用FeignClientsRegistrar扫描包下面的所有FeignClient。
使用SpringMvcContract解析相关spring mvc注解，生成LoadBalancerFeignClient动态代理
FeignClient底层使用ribbon进行负载均衡，调用对应的远程服务

@Import(FeignClientsRegistrar.class)
public @interface EnableFeignClients {
    //省略
}
//FeignClientsRegistrar类的重要方法
	@Override
	public void registerBeanDefinitions(AnnotationMetadata metadata,
			BeanDefinitionRegistry registry) {
        //注册bean
		registerDefaultConfiguration(metadata, registry);
        //扫描所有@FeignClient，解析注解中的所有属性。注册对应的FeignClient
		registerFeignClients(metadata, registry);
	}

	private void registerDefaultConfiguration(AnnotationMetadata metadata,
			BeanDefinitionRegistry registry) {
		Map<String, Object> defaultAttrs = metadata
				.getAnnotationAttributes(EnableFeignClients.class.getName(), true);

		if (defaultAttrs != null && defaultAttrs.containsKey("defaultConfiguration")) {
			String name;
			if (metadata.hasEnclosingClass()) {
				name = "default." + metadata.getEnclosingClassName();
			}
			else {
				name = "default." + metadata.getClassName();
			}
			registerClientConfiguration(registry, name,
					defaultAttrs.get("defaultConfiguration"));
		}
	}

	public void registerFeignClients(AnnotationMetadata metadata,
			BeanDefinitionRegistry registry) {

		LinkedHashSet<BeanDefinition> candidateComponents = new LinkedHashSet<>();
		Map<String, Object> attrs = metadata
				.getAnnotationAttributes(EnableFeignClients.class.getName());
//		AnnotationTypeFilter annotationTypeFilter = new AnnotationTypeFilter(
//				FeignClient.class);
		final Class<?>[] clients = attrs == null ? null
				: (Class<?>[]) attrs.get("clients");
		if (clients == null || clients.length == 0) {
			ClassPathScanningCandidateComponentProvider scanner = getScanner();
			scanner.setResourceLoader(this.resourceLoader);
            //扫描FeignClient
			scanner.addIncludeFilter(new AnnotationTypeFilter(FeignClient.class));
			Set<String> basePackages = getBasePackages(metadata);
			for (String basePackage : basePackages) {
				candidateComponents.addAll(scanner.findCandidateComponents(basePackage));
			}
		}
		else {
			for (Class<?> clazz : clients) {
				candidateComponents.add(new AnnotatedGenericBeanDefinition(clazz));
			}
		}

		for (BeanDefinition candidateComponent : candidateComponents) {
			if (candidateComponent instanceof AnnotatedBeanDefinition) {
				// verify annotated class is an interface
				AnnotatedBeanDefinition beanDefinition = (AnnotatedBeanDefinition) candidateComponent;
				AnnotationMetadata annotationMetadata = beanDefinition.getMetadata();
				Assert.isTrue(annotationMetadata.isInterface(),
						"@FeignClient can only be specified on an interface");

				Map<String, Object> attributes = annotationMetadata
						.getAnnotationAttributes(
								FeignClient.class.getCanonicalName());

				String name = getClientName(attributes);
				registerClientConfiguration(registry, name,
						attributes.get("configuration"));

				registerFeignClient(registry, annotationMetadata, attributes);
			}
		}
	}
	//解析FeignClient的所有属性，并注册FeignClientFactoryBean定义
	private void registerFeignClient(BeanDefinitionRegistry registry,
			AnnotationMetadata annotationMetadata, Map<String, Object> attributes) {
		String className = annotationMetadata.getClassName();
		BeanDefinitionBuilder definition = BeanDefinitionBuilder
				.genericBeanDefinition(FeignClientFactoryBean.class);
		validate(attributes);
		definition.addPropertyValue("url", getUrl(attributes));
		definition.addPropertyValue("path", getPath(attributes));
		String name = getName(attributes);
		definition.addPropertyValue("name", name);
		String contextId = getContextId(attributes);
		definition.addPropertyValue("contextId", contextId);
		definition.addPropertyValue("type", className);
		definition.addPropertyValue("decode404", attributes.get("decode404"));
		definition.addPropertyValue("fallback", attributes.get("fallback"));
		definition.addPropertyValue("fallbackFactory", attributes.get("fallbackFactory"));
		definition.setAutowireMode(AbstractBeanDefinition.AUTOWIRE_BY_TYPE);

		String alias = contextId + "FeignClient";
		AbstractBeanDefinition beanDefinition = definition.getBeanDefinition();
		beanDefinition.setAttribute(FactoryBean.OBJECT_TYPE_ATTRIBUTE, className);

		// has a default, won't be null
		boolean primary = (Boolean) attributes.get("primary");

		beanDefinition.setPrimary(primary);

		String qualifier = getQualifier(attributes);
		if (StringUtils.hasText(qualifier)) {
			alias = qualifier;
		}

		BeanDefinitionHolder holder = new BeanDefinitionHolder(beanDefinition, className,
				new String[] { alias });
		BeanDefinitionReaderUtils.registerBeanDefinition(holder, registry);
	}

java

FeignClientFactoryBean就是创建FeignClient组件的工厂

@Override
public Object getObject() throws Exception {
   return getTarget();
}

/**
 * @param <T> the target type of the Feign client
 * @return a {@link Feign} client created with the specified data and the context
 * information
 */
<T> T getTarget() {
   FeignContext context = applicationContext.getBean(FeignContext.class);
   Feign.Builder builder = feign(context);

   if (!StringUtils.hasText(url)) {
      if (!name.startsWith("http")) {
         url = "http://" + name;
      }
      else {
         url = name;
      }
      url += cleanPath();
      //生成动态代理
      return (T) loadBalance(builder, context,
            new HardCodedTarget<>(type, name, url));
   }
   if (StringUtils.hasText(url) && !url.startsWith("http")) {
      url = "http://" + url;
   }
   String url = this.url + cleanPath();
   Client client = getOptional(context, Client.class);
   if (client != null) {
      if (client instanceof LoadBalancerFeignClient) {
         // not load balancing because we have a url,
         // but ribbon is on the classpath, so unwrap
         client = ((LoadBalancerFeignClient) client).getDelegate();
      }
      if (client instanceof FeignBlockingLoadBalancerClient) {
         // not load balancing because we have a url,
         // but Spring Cloud LoadBalancer is on the classpath, so unwrap
         client = ((FeignBlockingLoadBalancerClient) client).getDelegate();
      }
      builder.client(client);
   }
   Targeter targeter = get(context, Targeter.class);
   //生成动态代理
   return (T) targeter.target(this, builder, context,
         new HardCodedTarget<>(type, name, url));
}
	protected <T> T loadBalance(Feign.Builder builder, FeignContext context,
			HardCodedTarget<T> target) {
		Client client = getOptional(context, Client.class);
		if (client != null) {
			builder.client(client);
			Targeter targeter = get(context, Targeter.class);
			return targeter.target(this, builder, context, target);
		}

		throw new IllegalStateException(
				"No Feign Client for loadBalancing defined. Did you forget to include spring-cloud-starter-netflix-ribbon?");
	}

java

此处获取的Targeter在FeignAutoConfiguration注册

@Configuration(proxyBeanMethods = false)
@ConditionalOnClass(name = "feign.hystrix.HystrixFeign")
protected static class HystrixFeignTargeterConfiguration {

   @Bean
   @ConditionalOnMissingBean
   public Targeter feignTargeter() {
      return new HystrixTargeter();
   }

}

@Configuration(proxyBeanMethods = false)
@ConditionalOnMissingClass("feign.hystrix.HystrixFeign")
protected static class DefaultFeignTargeterConfiguration {

   @Bean
   @ConditionalOnMissingBean
   public Targeter feignTargeter() {
      return new DefaultTargeter();
   }

}

java

Feign.Builder最后调用build创建ReflectiveFeign实例，调用newInstance方法，使用动态代理创建FeignClient。

public <T> T newInstance(Target<T> target) {
  Map<String, MethodHandler> nameToHandler = targetToHandlersByName.apply(target);
  Map<Method, MethodHandler> methodToHandler = new LinkedHashMap<Method, MethodHandler>();
  List<DefaultMethodHandler> defaultMethodHandlers = new LinkedList<DefaultMethodHandler>();

  for (Method method : target.type().getMethods()) {
      //过滤object的方法
    if (method.getDeclaringClass() == Object.class) {
      continue;
    } //是否默认方法
      else if (Util.isDefault(method)) {
      DefaultMethodHandler handler = new DefaultMethodHandler(method);
      defaultMethodHandlers.add(handler);
      methodToHandler.put(method, handler);
    } else {
      methodToHandler.put(method, nameToHandler.get(Feign.configKey(target.type(), method)));
    }
  }
  InvocationHandler handler = factory.create(target, methodToHandler);
  T proxy = (T) Proxy.newProxyInstance(target.type().getClassLoader(),
      new Class<?>[] {target.type()}, handler);

  for (DefaultMethodHandler defaultMethodHandler : defaultMethodHandlers) {
    defaultMethodHandler.bindTo(proxy);
  }
  return proxy;
}

java
